9in Monitor 4 cameras

Quad 9in Monitor – 4 Camera Kit for Truck – Tractor – Combine

£370.80 inc VAT

Ideal vehicle CCTV system for tipper lorry, artic lorry (needs trailer connecting cable TGA1), agricultural tractors and equipment, municipal vehicles, refuse collection vehicles, cranes etc.

Cover the blind spots or view important areas, position cameras for any view forward, backward or sides.

Has clear night vision with Infra Red LEDs fitted in cameras.

Choose which cameras – other combinations available ( please ask ).

SKU: N/A Category: Tag:

Description

TFT LCD Color Monitor(Model:TG902)
9″Digital Screen TFT LCD Color Monitor with Sun Visor
OSD MENU Separately Set Each Camera Trigger Priority
OSD MENU Separately Set Each Camera Reversing Image Delay Time 0-30″
OSD MENU Separately Set Each Camera Mirror/Normal image
Manual and Automatic Switch Display Mode
Color System:PAL/NTSC (AUTO)
Display Resolution: 800RGB(H) X 480(V) dot
Support 2 channel Camera Video Audio Inputs:1.0Vp-p75Ω
Wide view angle(CR:10):(up/ down): 45/65 (left/right): 65/65
Contrast ratio: 500:1
Back-light : Single LED 400cd/m2 Brightness
Operating temperature: -20℃ to +70℃
Storage temperature: -30℃ to +80℃
Load Dump: DC14+67V(Td400mS) 5pulses
Free Operating Voltage DC11-32V
External dimensions: (L x W x T) (234 x158 x 81mm) with mounting Sun Visor
Weight Approx: 479g

Reversing  Camera
Style 4 PIN
Image sensor 1/4 inch CMOS
TV system PAL / NTSC
Effective Pixel PAL: 628(H) x 582(V); NTSC: 510(H) x 492(V)
Sensing Area 5.78mm x 4.19mm/ 4.69mm x 3.54mm
Sync. system: Internal
Minimum Illumination: 0.1 – 0.5Lux/F=1.2
Horizontal Resolutions: 420 TV lines<>
S/N Ratio: More than 48db
Night vision: Yes
View Angle: 120>
Video output: RCA connector, 1.0V p-p, 75ohm
Power Supply: DC12V-24V
High-definition and wide viewing angles
18 infrared lamp used in low light condition
Waterproof IR camera with 120° wide view angle
Monitor can be easily adjusted at multi-level angle
Adjustable shade to prevent glare from sun
Auto showing image when backing up truck
Top quality camera, easy and safe to mount

Sideview Camera
Sensor 1/4 Sharp CCD
Resolution: P: 500×582 pixels
Lens: 2.5mm
Min illumination: 0.1 Lux (LED ON)
IR led: 9pcs
Night Vision distance: 35ft
Waterproof IP68
View angle: 120°
Power voltage: 12V
Operation Temp.: -20℃~+70℃
